PETERSON

LED HeadLamp Insert 7in 9-32V High/Low Beam +Park Beam ADR/ECE Approved

LED HeadLamp Insert 7in 9-32V High/Low Beam +Park Beam ADR/ECE Approved

$686.51
$789.49 $686.51
Sale Sold out
Designed, engineered and manufactured in the USA with state-of-the-art optics And LED technology, the 7inch navigator produces a dramatically crisp beam with a Wider, more even pattern and colour temperature that closely matches daylight. ADR legal LED drop in replacement for standard 7inch head lamp inserts, the Navigator delivers superior construction quality and extreme durability and Features high, low beam and park functions in the one amp.Features: 7inch round LED head lamp ADR/ECE approved for all functions Lifetime warranty High/Low beam with park light. A direct replacement for 7 inch sealed and semi sealed beam headlights. Standard H4 type plug connection. Fits standard headlight cradle and bucket mounts. 9-32V input with low current draw complete with standard h4 plug 100% Designed and manufactured in the USA.Specifications 7 inch diameter. Multi volt input. (9-32 volt.) Low beam lumens: 1350. High beam lumens : 1700. Colour temperature: 5400 to 6300. UV and impact resistant, hard-coated poly carbonate lens. 100% MADE-IN-USA BY PETERSONPeterson's Navigator 7inch LED head lamps are 100% designed, engineered and manufactured in the USA! Established in 1945 and with a heritage of building quality products stretching over 70 years, Peterson Manufacturing from the USA are trusted by the world's leading manufacturers. OEM on legendary American-made Cat's and Harley's for over a quarter century, Peterson Manufacturing are proud to be the brand that lights up legends!INVESTMENT FOR A LIFETIMENavigator offers ultimate performance, durability and are built to last a lifetime*. With Peterson's Limited Lifetime Warranty, UV & impact resistant, hard coated polycarbonate lenses, vacuum metallised reflectors and heavy duty die cast aluminium housings, they offer superior construction quality and extreme durability.

Cross References:

72102, 27291C

Specs:

Current Draw L/B: 2.1Amps; H/B: 2.2Amps
Specification1 Colour Temperature: 5400 - 6300K
Approvals CTA-061089
Specification5 Wiring Connection: Integrated H4 Plug
Specification3 Depth: 99mm
Specification4 Power Consumption: L/B: 28W; H/B: 29W
Specification2 Current Draw @ 24V: L/B: 1.0Amp; H/B: 1.1A
Warranty Lifetime
Brand PETERSON
Voltage 9 - 32Vdc
Housing Material Heavy Duty cast Aluminium
Lens material Hard Coated Polycarbonate
Diameter 178mm
LUMENS L/B: 1350; H/B: 1700

Range Features

Specifications
